Solution Accuracy
SPS………………………………………………………………1.2 m cep
RTK……………………………………………………………0.02 m cep
60s GNSS Outage…………………………< 1.0 m rms
Velocity Accuracy…………………………………………0.01 m/s rms
Heading Accuracy………………………………………0.2° rms
Attitude Accuracy (Roll/Pitch)………………0.02° rms
IMU Performance
GNSS & Timing
Signal Bands……………………… L1 C/A, L2C, L1OF, L2OF, B1I, B2I, E1, E5b and SBAS
RTK Initialization Time…. <1 min, using RTCM3 corrections
Output Data Rate…………………… 200 Hz
Synchronization…………………………PPS Out, PPS Sync In, PTP
Environment
Operating Temperature ………………….-40 to +70°C
Vibration ………………………………………………………… 5g rms
Shock Survival ………………………… 40g
Electrical
Input Voltage …………………………………… 8 to 30 Vdc
Power Consumption …………………… 4 W typical
Digital Interface ………………. Ethernet, RS-232 (2 Ports)
Physical
Size……………………………………. 5.8” x 4.3” x 1.3”
Weight……………………………. 1 lbs.
